SPECIFICATIONS

Brand Name: NDECYC

Design: Brushless

Motor: Brushless Non-gear Hub Motor

Mounting Position: Rear Drive

Voltage: 72 V

Wattage: > 1000w

brake type: disc brake

dropout width: 170MM / 190MM

freewheel: seven speed as default

rated power: 3000W / 5000W

rim width: 80mm by defalt

voltage: 48-96V

NBP 170mm / 190mm Dropout Width 3000W 5000W Motor Wheel, Fat Bike Motor Wheel

if need tire please contact us before order, need extra fee.

80mm width rim as default

Packaging list

1. a motorwheel, 80mm width rim as default (if need 100mm please contact us)

2. a freewheel (seven speed as default, if need single speed please let us know)

5000w 190m 20inch have US stock, 100mm rim width with single speed（now sold out, will have US stock again after a month）

Specification

1. Motor Type: BLDC In-Wheel Hub Motor

2. Motor Design: Double Axle

3. Matched Tire: 17inch-29inch

4. spokes: 36holes

5. Rated Voltage: 72V

6. Speed: 960rpm 850rpm

7. Drop-outs: 170/190mm

8. Max Efficiency: approx 91%

9. Thermic Probe: KTY83/122(as default)

10. Working Temperature: 70-120℃, peak 150℃

11. Brake Type: Disc Brake

12. Hall Sensor: Dual hall set with waterproof connector

13. Waterproof Grade: IP65

14. pole pairs: 23

190 motor diagram

170 motor diagram
